SEA FREIGHT: Shipping containers is either by 20ft FCl or 40ft FCL. See the below stats.
SHIPPING CONTAINERS SIZES AND TYPES
Dry containers come in several sizes 20-40ft or FCLs:
• 20' with a payload up to 28.3 metric tons
• 40' - both 8'6" and 9'6" high cube - with a payload up to 30.4 metric tons
• 45' - 9'6" high cube - with a total capacity of 86 cubic metres
20ft standard 20' x 8 x 8.6" Cubic Capacity
33.2m2 or 1172ft
|
Weight
|
Max Payload
|
Max Gross Weight
|
Internal length
|
Internal Width
|
Internal Height
|
|
2300 kgs
|
28180 kgs
|
30480 kg
|
5898mm
|
2352mm
|
2393 mm
|
|
5070 lb
|
62130 lb
|
67200 lb
|
19'4"
|
7'9"
|
7'10"
|
40ft standard 40' x 8 x 8.6" Cubic Capacity
67.7m2 or 2390ft
|
Weight
|
Max Payload
|
Max Gross Weight
|
Internal length
|
Internal Width
|
Internal Height
|
|
3750 kgs
|
28750 kgs
|
32500 kg
|
12032mm
|
2352mm
|
2393 mm
|
|
8265 lb
|
63385 lb
|
71650 lb
|
39'6"
|
7'9"
|
7'10"
|
40ft high cube 40' x 8 x 9.6" Cubic Capacity
76.4m2 or 2700ft
|
Weight
|
Max Payload
|
Max Gross Weight
|
Internal length
|
Internal Width
|
Internal Height
|
|
3940 kgs
|
28560 kgs
|
32500 kg
|
12032mm
|
2352mm
|
2698 mm
|
|
8685 lb
|
62965 lb
|
71650 lb
|
39'6"
|
7'9"
|
8'10"
|
REEFER CONTAINERS: 20 & 40ft FCL
• Refrigerator container with a cargo temperature of -27 degrees C/ -15 degrees F & maintaining temperatures as low as -60 degrees C/ -76 degrees F
• Dehumidification system ensuring the optimal humidity inside the container
• Controlled atmosphere improving quality and shelf life
• Environmentally-friendly CFC free R-134A refrigerant
• Ideal for frsh and frozen vegetables, meat, shell fish etc
FLATRACKS & BULK CARRIER Many sizes 20-40ft
There are several options for oversized or especially heavy cargo like excavators and machinery etc.
20ft and 40ft flat racks have fixed or collapsible end-walls. They are suitable for top or side loading and ideal for heavy machinery, cranes, excavators, oil rigs, pipes, etc.
20ft and 40ft open-top containers, have removable roof bows and tarpaulin covers.
20ft open-top/open-side containers, have removable side grating, top rails, roof bows and door headers. These containers are designed for easy stuffing and stripping. They also allow good ventilation.
20ft and 40ft flat racks have fixed or collapsible end-walls. They are suitable for top or side loading and ideal for heavy machinery, cranes, excavators, oil rigs, pipes, etc.
|
| |
Flat Rack Containers |
Interior Dimensions |
Tare Weight |
Payload |
20' Flat Rack Container |
L: 5,935 mm |
2,560 kg. |
21,440 kg. |
W: 2,398 mm |
5,643 lbs. |
47,265 lbs. |
H: 2,327 mm |
|
|
20' Collapsible Flat Rack Container |
L: 5,966 mm |
2,970 kg. |
27,510 kg. |
W: 2,418 mm |
6,547 lbs. |
60,647 lbs. |
H: 2,286 mm |
|
|
40' Flat Rack Container |
L: 12,080 mm |
5,480 kg. |
25,00 kg. |
W: 2,438 mm |
12,080 lbs. |
55,113 lbs. |
H: 2,103 mm |
|
|
40' Collapsible Flat Rack Container |
L: 12,178 mm |
5,200 kg. |
39,800 kg. |
W: 2,438 mm |
11,463 lbs. |
87,741 lbs. |
H: 1,943 mm |
|
|
|
|
|
|
When sending a shipment by sea we need to know the following information
| What are you sending |
Destination port of entry |
How many cbm (cubic metres) |
Pickup or you deliver to us |
SENDING GOODS OUT OF THAILAND:
When asking us for a quotation and you wish to send personal items please tell us exactly what you are shipping. Itemize all articles so we can tell you if you need fumigation, clearance from Customs and Fine Arts depts etc. We will not quote you if you do not list all items you wish to ship. Try to work out how many cubic metres you need to ship. Min 1cbm and this means 1m x1m x1m. LCL = MEANS LOWER THAN CONTAINER LEVELS. Over 1cbm the price gets cheaper so the more you do the cheaper it becomes.
BUDDHA HEADS OR STATUES:
Buddha heads are very sentitive for Thais to send so be aware as many shippers will not ship because one item may be a head that now needs to be cleared by the Dept of Fine Arst and the Customs. Many headaches shipping these now so we do not send relics even if copies. AS FROM 2008 OUR COMPANY CAN SHIP BUDDHA HEADS OR MASKS OF ANY MAKE OR KIND THAT ARE BUDDHA COPIES ETC. BUT BE AWARE OF THE CUSTOMS CHARGES
